Scooters

Hugo® Pack & Go Scooters

Sapphire Blue or Garnet Red

The easy-to-use Hugo® Pack & Go Scooter’s lightweight, compact
design allows it to fit into the trunk of your car, so you can take it
with you anywhere you want to go.

What’s more, it assembles in just minutes and comes with
everything you need packed in a box.

Pack & Go Scooter in car trunk • 10 km cruising range.
• 6.4 km/h top speed.
• Forward / Reverse control levers.
• Maximum speed control dial.
• Rechargeable battery pack.
• Height adjustable seat with flip-up arms.
• Adjustable angle steering tiller.
• Breaks down for easy transport.
• 1 Year warranty on frame, electronic controller, and drive train components.

Hugo® Pack & Go Scooter literature sheet

Scooter accessories

Assembly diagrams and parts lists (pdf file)

Instruction manual (pdf file)

Specifications

Dimension (L x W x H)	960 x 535 x 890 mm 37.8” x 21.1” x 35”	Brake System	Electromagnetic
Weight, With Battery W/O Battery	81.2 Lbs (36.9 kg) 59.8 Lbs (27.2 kg)	Control Method	Speed control lever
Battery	12V 12 AH x 2	Top Speed (Forward)	6.4 km/h (4 Mph)
Charger	24V 2A	Reverse	3.84 km/h (2.4 Mph)
Front Tire	200 x 50 solid tire	Climbing Angle	8º
Rear Tire	200 x 70 solid tire	Cruising Range	10 km (6.2 Miles)
Driving System	Direct rear wheels (with differential gear)	Min. Turning Radius	615 mm (24.2”)
Max. Load Weight	250 Lbs
